ST 120-160

Category: Single Serie

Specifications

Application:

Suitable for mounting single- and multiple-conductor low- medium- and
high voltage cables.

Range:

For cables with a nominal outer diameter of 120 up to 160 mm.

Material:

Black polyamide (PA66), fibreglass-reinforced, virgin material.

Fire resistance:

UL94 V-0 and classification standard EN 45545-2: 2020 – Railway applications. Requirement set R22,R23 / Hazard level HL1,HL2.

Standards:

Certified in accordance with the international standard NEN-EN-IEC 61914:2021

Temperature:

Permanent application from -80˚C to +120˚C. Short-term heating of up to +220˚C.

Advantages:

Resistant to oils, greases, frost, heat, UV, ozone, salt water, salts, acids and aggressive chemicals. Non-oxidizing, non-corrosive, non-magnetic and non-conductive. Halogen-free and no sharp edges. Lifetime warranty, easy assembly and available worldwide.

Extra Possibilities:

Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s

Inquire Now Download Datasheet

Product Dimensions

The product listed in this datasheet is produced in conformity with the latest EU Directive 2011/65 / EU (RoHS), and complies with all legal obligations in accordance with REACH.

Dimensions in millimeters
